| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 12 |
| Mode: | AM |
| Frequency control: | Two XTALs per channel |
| Frequency stability: | ?% |
| Clarifier or Delta tune: | No |
| Power supply: | 13-18 VDC (Twelve R6 / AA alkaline or NiCd batteries)
or 12 VDC external |
| Current drain / power consumption: | RX: ? mA
TX: ? A |
| Antenna impedance / connector: | Fixed telescopic whip
50 ohm / ? jack |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: |
PA. Battery meter. Charging jack. Range boost.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | 0.7 uV (No S/N reference) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power/speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~3.5 W (5 W input) |
| Modulation system: | |
| Max AM modulation (Factory set): | ?% |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1969-1971 (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price 1969 in the US: $99.95 (With XTALs for channel 10)
New price 1970 in the US: $99.95 (With XTALs for channel 10)
New price 1971 in the US: $99.95 (With XTALs for channel 10)
|
| Related documents: | |
| Known markets and approvals: |
USA
FCC
|
| Sams Photofact #: | CB-25 (December 1969) |
| Modifications and fixes: | |
| Reviews: | |
| Options/Accessories: |
|
