| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 23 |
| Mode: | AM |
| Frequency control: | XTAL matrix |
| Frequency stability: | ?% |
| Clarifier or Delta tune: | ±? KHz "Fine tuning" |
| Power supply: | Mains: 110-120 VAC (Male 2-pin jack)
or 13.8 VDC (Spade connector) |
| Current drain / power consumption: | RX: ? W @ mains
TX: ? W @ mains |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: |
PA. ANL.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: 455 KHz
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / 8 ohm |
| External speaker connector: | TS 1/4" jack |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
4 W
|
| Modulation system: | |
| Max AM modulation (Factory set): | ?% |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 4-pin (Male GX16 locking ring jack) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1975-1976 (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price 1975 in the US: $169.00
New price 1976 in the US: $169.00
|
| Related documents: | |
| Known markets and approvals: |
USA
FCC Data: 981-6235
|
| Sams Photofact #: | CB-100 (October 1976) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
