| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: |
Standard
26.965-27.255 MHz
Can be aligned to any 300 KHz segment between 27-31 MHz
|
| Channels / tuning steps: | 6 |
| Mode: | AM |
| Frequency control: | Two XTALs per channel |
| Frequency stability: | ±?% |
| Clarifier or Delta tune: | No |
| Power supply: | 12 VDC (Eight LR6 / AA alkaline or ten R6 / AA NiCd batteries) |
| Current drain / power consumption: | RX: 22 mA (Minimum output)
TX: Max 625 mA (No modulation) |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 75*250*60 mm (2.95*9.84*2.36") |
| Weight: | 585 g (1.29 lb), without batteries |
| Other features: | Internal selcall option. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | 0.6 uV (10 dB S+N/N) |
| Squelch sensitivity: | |
| Selectivity: | 6 KHz (-6 dB)
20 KHz (-60 dB) |
| Image rejection: | |
| AF output power / speaker: | 2 W at 10% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
High: ~3 W (5 W input)
Low: ~600 mW (1 W input)
|
| Modulation system: | |
| Max AM modulation (Factory set): | ?% |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1980-198x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: | |
| Related documents: | |
| Known markets and approvals: |
Sweden
Televerket: ?
USA
FCC Data: ?
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
