| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 3 |
| Mode: | AM |
| Frequency control: | Two XTAL's per channel |
| Frequency stability: | ±0.005% (No temperature reference) |
| Clarifier or Delta tune: | No |
| Power supply: | 9 VDC (One 6LR61 / 1604 / E battery) |
| Current drain / power consumption: | RX: 20-60 mA (No signal)
TX: Max 60 mA |
| Antenna impedance / connector: | Fixed telescopic whip |
| Dimensions (W*H*D): | 70*203*50 mm (2.76*7.99*1.97") |
| Weight: | 419 g (14.78 oz) |
| Other features: | Tone call. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 100 mW at ?% distortion / 8 ohm |
| External speaker connector: | - |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~60 mW (100 mW input) |
| Modulation system: | High level class B push-pull |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | 8 ohm / Internal only |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Taiwan, 1976-1978 (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price 1977 in Sweden: SEK 98:-
New price 1979 in Sweden: SEK 132:-
|
| Related documents: |
User manual (2.2 MB)
|
| Market(s) / Approval(s): | |
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
