| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 23 (1-22 + 11A) |
| Mode: | AM |
| Frequency control: | XTAL-matrix (15 XTALs) |
| Frequency stability: | ±?% |
| Clarifier or Delta tune: | No |
| Power supply: | 12-15 VDC |
| Current drain / power consumption: | RX: ? mA
TX: ? A |
| Antenna impedance / connector: | 52 ohm / SO-239 |
| Dimensions (W*H*D): | 197*57*248 mm (7.75*2.25*9.75") |
| Weight: | 2.04 Kg (4.5 lb) |
| Other features: |
ANL. Dual watch and scanning. External selcall option.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.635 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.5 uV (6 dB S+N/N) |
| Squelch sensitivity: | 1 uV (Threshold)
500 uV (Tight) |
| Selectivity: | 10 KHz (-6 dB) |
| Image rejection: | |
| AF output power / speaker: | 2.5 W at ?% distortion / ? ohm |
| External speaker connector: | TS 1/4" jack, 8 ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | ~3.1 W (5 W input) |
| Modulation system: | High level class B |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | 2 Kohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 197x-197x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
Clearance price 1983 in Sweden: SEK 364:-
|
| Related documents: |
User manual (1 MB)
|
| Known markets and approvals: |
Sweden
Kungliga Telestyrelsen
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
