| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.405 MHz |
| Channels / tuning steps: | 40 |
| Mode: | AM / SSB |
| Frequency control: | PLL |
| Frequency stability: | ±?% |
| Clarifier or Delta tune: | ±? Hz "Voice lock" |
| Power supply: | 11.7-15.9 VDC (Male 3-pin jack) |
| Current drain / power consumption: | RX: 250-600 mA
TX: Max 2.2 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 200*60*235 mm (7.87*2.38*9.25") |
| Weight: | 2.27 Kg (5 lb) |
| Other features: | PA. ANL/NB. Dimmer. SWR-meter. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne (SSB)
IF: 7.8 MHz
Double conversion superheterodyne (AM)
1st IF: 7.8 MHz
2nd IF: 455 KHz
|
| Sensitivity: |
AM: 0.5 uV (10 dB S+N/N)
SSB: 0.25 uV (10 dB S+N/N)
|
| Squelch sensitivity: | Less than 0.25 uV (Treshold) |
| Selectivity: |
AM: 3 KHz (-6 dB), 9 KHz (-50 dB)
SSB: 1.1 KHz (-6 dB), 2.3 KHz (-60 dB)
|
| Image rejection: | 65 dB |
| AF output power / speaker: | 4 W at ?% distortion / 4 ohm |
| External speaker connector: | 3.5 mm, 4-8 ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | AM: 4 W
SSB: 12 W (PEP) |
| Modulation system: | AM: High- and low-level, class B
SSB: ? |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 4-pin (Front mounted male locking ring jack) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Thailand and China, 2002-201x (Discontinued) |
| Main PCB: | KEPC-332-E by ? |
| Sub PCBs: | |
| Additional info: | |
| Related documents: |
User manual (301 KB)
RF driver: 2SC2166
RF final: 2SC1969
|
| Market / Approval: |
USA
FCC ID: BBO3K2148GTL
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
