| GENERAL |
| Type: | Citizen band / "Freeband" / Export transceiver |
| Frequency range: |
26.965-27.405 MHz (Standard)
25.165-29.655 MHz (Export mode)
|
| Channels / tuning steps: | 40 (Standard)
400 (Export mode) |
| Mode: | AM / SSB |
| Frequency control: | PLL/CPU (LC7232) |
| Frequency stability: | ?% |
| Clarifier or Delta tune: | ±? KHz |
| Power supply: | Mains: 117 VAC (Fixed power cord) |
| Current drain / power consumption: | RX: ? mA
TX: ? A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 305*89*254 mm (12*3.5*10") |
| Weight: | ? Kg (? lb) |
| Other features: |
ANL/NB. Channel 9/19 button. Dual watch. 5 memories. Scanning. Dimmer.
SWR-meter. 10 NOAA weather channels.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
AM: 4 W
SSB: 12 W (PEP)
|
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 5-pin (Metal locking ring connector) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Philippines, 1996-199x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
Indicated price, november 1996 in the US: $499.95 (MSRP)
New price, december 1996 in the US: $279.95
|
| Related documents: | PLL/CPU: LC7232 |
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | Popular Communications: August 1997 |
| Options / Accessories: |
|
