| GENERAL |
| Type: | Citizen band / Freeband / Export transceiver |
| Frequency range: |
Export mode
24.715-30.105 MHz
|
| Channels / tuning steps: |
Channel mode
480 + alphas
VFO mode
10 / 100 Hz, 1 / 5 / 10 / 100 KHz, 1 MHz
|
| Mode: | AM / FM / SSB / CW |
| Frequency control: | PLL/CPU |
| Frequency stability: | ?% |
| Clarifier or Delta tune: | ±? KHz |
| Power supply: | 13.8 VDC |
| Current drain / power consumption: | RX: ? mA
TX: ? A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 180*54*185 mm (7.06*2.12*7.28") |
| Weight: | 1 Kg (2.2 lb) |
| Other features: |
PA. ANL/NB. CTCSS/PL and DCS. 5-level NRC (RX/TX Noise reduction).
Dimmer. VOX. Echo. Dual watch. Scanning. SWR meter. Roger beep. ASQ.
Tone hi-cut. +10 KHz button. PC programmable (USB-C).
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne (SSB/CW)
IF: 10.695 MHz
Double conversion superheterodyne (AM/FM)
1st IF: 10.695 MHz
2nd IF: 455 KHz
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
AM: 35 W (PEP)
FM: 30 W
SSB: 30 W (PEP)
CW: 30 W
|
| Modulation system: | |
| Max AM modulation (Factory set): | ?% |
| Max FM deviation (Factory set): | ±? KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin (Male GX16 locking ring jack) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2026-202x |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: | |
| Related documents: | |
| Known markets and approvals: |
Export
No known approvals for CB use
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
