| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: |
Europe and Australia
25-512 MHz
806-956 MHz
1240-1300 MHz
|
| Tuning steps: | 5 / 7.5 / 10 / 12.5 / 25 / 50 / 100 KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / NFM / WFM |
| Channels / memory management: |
500 regular in 10 banks @ 100 channels per second. Alpha tags
10 priority
Scan resume delay: None, 1 / 2 / 4 seconds or infinite
Non-volatile EEPROM storage
|
| Power supply: | 13.8 VDC (Male barrel jack, center positive) |
| Current drain / power consumption: | Less than 700 mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 177*72*195 mm (6.97*2.84*7.68") |
| Weight: | 1.33 Kg (2.93 lb) |
| Other features: |
CTCSS/PL and DCS. Tracks Motorola, EDACS and LTR systems.
PC-programmable via RS-232C. Attenuator. Dimmer.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne (WFM)
1st IF: 380.7 MHz (244 MHz for the 311-512 MHz range)
2nd IF: 10.7 MHz
Triple conversion superheterodyne (AM/FM/NFM)
1st IF: 380.7 MHz (244 MHz for the 311-512 MHz range)
2nd IF: 45 MHz
3rd IF: 450 KHz
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 2.3 W at 10% distortion / 8 ohm |
| External speaker connector: | 3.5 mm, 8 ohm |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Philippines and China (Designed in Japan), 2001-2006 (Discontinued) |
| Additional info: |
PH-262AB - Main board
PH-263AA 1/4 - Front panel board
PH-263AA 2/4 - Volume/squelch board
PH-263AA 3/4 - VFO/Select board
PH-263AA 4/4 - 2SD1667 board
New price 2006 in Sweden: SEK 2895:-
|
| Related documents: |
User manual (3.2 MB)
User manual (3.2 MB, in swedish)
AF amplifier: TDA1905
AM tuner: LA1600
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
