| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: | 66-88 / 137-174 / 406-512 MHz |
| Tuning steps: | 5 / 12.5 KHz |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
80 regular @ 10 channels per second
5 search bands
1 priority
RAM storage with capacitor backup (About 1 hr retention)
|
| Power supply: | 4.8-6 VDC (Four R6 / AA batteries)
or 12 VDC external (Barrel connector, center positive) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 64*180*38 mm (2.52*7.09*") |
| Weight: | 400 g ( oz) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 240 mW at ?% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Philippines (Designed in Japan), 200x-200x (Discontinued) |
| Additional info: | |
| Related documents: | User manual (1.2 MB, Eng/Ger/NL) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
