| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: | 25-54 / 108-174 / 406-512 MHz |
| Tuning steps: | 5 / 6.25 / 7.5 / 8.33 / 12.5 KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / NFM |
| Channels / memory management: |
500 regular in 10 banks @ up to 90 channels per second
Priority function
|
| Power supply: | 2.4-3 VDC (Two R6 / AA alkaline or NiMH batteries)
or 5 VDC external (USB Mini jack) |
| Current drain / power consumption: | 120-280 mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 67*115*33 mm (2.64*4.53*1.3") |
| Weight: | 175 g (6.17 oz), without battery and antenna |
| Other features: | Close Call RF capture. PC programmable. USB Mini. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Triple conversion superheterodyne
1st IF: 265.505-265.600 MHz
2nd IF: 21.3 MHz
3rd IF: 450 KHz
|
| Sensitivity: |
AM: 0.3 uV (12 dB SINAD)
FM: 0.2 uV (12 dB SINAD)
NFM: 0.2-0.3 uV (12 dB SINAD)
|
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 360 mW at ?% distortion / 24 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Vietnam, 2019-202x |
| Additional info: |
New price, september 2025 in the US: $129.99
|
| Related documents: | User manual (2.9 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
