| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: | 29-54 / 108-174 / 406-512 / 806-956 MHz
(Cellular blocked in the US) |
| Tuning steps: | 5 / 12.5 KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM |
| Channels / memory management: |
100 regular in 10 banks @ 100 ch/second
10 priority. 1 per bank
7 NOAA weather channels
RAM storage with capacitor backup. Approximately 3 to 14 days
memory retention without batteries.
|
| Power supply: | 4.8 VDC (NiCd battery pack) or 6 VDC external |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 64*311*44 mm (2.5*12.25*1.75"), with antenna |
| Weight: | 349 g (12.32 oz) |
| Other features: | Data skip. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Triple conversion superheterodyne
1st IF: ? MHz
2nd IF: ? MHz
3rd IF: ? KHz
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 180 mW at ?% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Philippines, 1994-199x (Discontinued) |
| Additional info: | |
| Related documents: | User manual (361 KB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
AD-70U
AT-218
BCK-150
BP-180
EP-009
LC-150B
LC-150Y
MPK-150
UA-502
UA-502A
|
AC adapter
Rubber antenna
Belt clip
NiCd battery pack. 4.8 V, 800 mAh
Earphone
Black leather carrying case
Yellow leather carrying case
Pack of direct channel memo pads
Cigarette lighter power cord
Coiled cigarette lighter power cord
|
|
