| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: | 25-54 / 108-174 / 406-512 / 806-956 MHz (Cellular blocked in the US) |
| Tuning steps: | 5 or 12.5 KHz (Depending on band) |
| Frequency stability: | ? ppm |
| Mode: | AM / FM |
| Channels / memory management: |
3670 pre-programmed non-erasable public service and CB channels
100 "Police" and FD/EMG" user programmable channels
100 "Air" and "Marine" user programmable channels
100 "Private" user programmable channels
13 search bands
|
| Power supply: | 13.8 VDC (Barrel connector, center positive) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 132*41*146 mm (5.19*1.62*5.75") |
| Weight: | 638 g (1.41 lbs) |
| Other features: | Close Call RF capture technology. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: |
25-28 MHz: 0.4 uV (12 dB SINAD)
28-54 MHz: 0.2 uV (12 dB SINAD)
108-137 MHz: 0.4 uV (12 dB SINAD)
137-174 MHz: 0.2 uV (12 dB SINAD)
406-512 MHz: 0.3 uV (12 dB SINAD)
806-956 MHz: 0.4 uV (12 dB SINAD)
|
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 1.2 W at ?% distortion / ? ohm |
| External speaker connector: | 3.5 mm, 8 ohm |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2009-2011 (Discontinued) |
| Additional info: | |
| Related documents: | User manual (5 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
ESP-5
ESP-12
ESP-20
MB-007
|
External speaker
External speaker
External speaker
Mobile mounting bracket
|
|
