| GENERAL |
| Type: | HF/VHF/UHF receiver/scanner |
| Frequency range: |
8-600 / 805-1300 MHz
|
| Tuning steps: | 5 to 995 KHz |
| Frequency stability: | ? ppm |
| Mode: | AM / FM / WFM |
| Channels / memory management: |
1000 regular in 10 banks @ 20 channels per second
10 search banks
Priority function
|
| Power supply: | 4.8-6 VDC (Four LR6 / AA batteries)
or 11-15 VDC external |
| Current drain / power consumption: | 80-100 mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 65*170*35 mm (2.56*6.69*1.38") |
| Weight: | 300 g (10.58 oz), without batteries |
| Other features: | Attenuator. Backlit display. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Triple conversion superheterodyne
1st IF: 561.225 MHz
2nd IF: 58.075 MHz
3rd IF: 455 KHz (10.7 MHz for WFM)
|
| Sensitivity: |
AM: 3 uV (No reference)
FM: 0.5 uV (No reference)
|
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 100 mW at 10% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan (By Nissei Corporation), 19xx-19xx (Discontinued) |
| Additional info: | |
| Related documents: | User manual (187 KB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
