| GENERAL |
| System: | NMT450 System base (Sweden and other Nordic countries) |
| Frequency range: | TX: 463.000-467.500 MHz
RX: 453.000-457.500 MHz |
| Frequency stability: | ? ppm |
| Power supply: | 24 VDC ±2% |
| Current drain / power consumption: | Max 4.8 A (+200 mA with diversity) @ 50 W output power |
| Impedance / antenna: | 50 ohm / ? |
| Dimensions (W*H*D): | 434*65*354 mm (17.1*2.6*13.9"), overall including cooling fins |
| Weight: | 8.9 Kg (19.6 lb) |
| Other: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / impedance: | ? mW at ?% distortion / ? ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
50 W nominal, 100% duty cycle (0.5-55 W adjustable)
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Handset impedance / connector: | - |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Sweden, 198x-198x (Discontinued) |
| Additional info: |
Diversity RX option. Compatible with ATF2.
|
| Related documents: | |
| Modifications and fixes: | |
| Options / Accessories: |
|
