| GENERAL |
| System: | NMT450 System base (Sweden and other Nordic countries) |
| Frequency range: | TX: 463.000-467.500 MHz
RX: 453.000-457.500 MHz |
| Frequency stability: | ? ppm |
| Power supply: | Mains: 220 VAC |
| Current drain / power consumption: | Max ? W |
| Impedance / antenna: | 50 ohm / N-jack (TX), TNC (RX) |
| Dimensions (W*H*D): | 430*88*400 mm (16.92*3.46*15.75") |
| Weight: | 9.2 Kg (20.3 lb) |
| Other: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 21.4 MHz
2nd IF: 455 KHz
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / impedance: | ? mW at ?% distortion / ? ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
3 / 12 / 50 W switchable
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Handset impedance / connector: | - |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 198x-198x (Discontinued) |
| Additional info: |
Without external system control, the unit
defaults to 463.000 (TX) / 453.000 (RX)
|
| Related documents: | |
| Modifications and fixes: | |
| Options / Accessories: |
|
