| GENERAL |
| System: | MTD (Sweden) |
| Frequency range: | TX: 453.000-457.500 MHz
RX: 463.000-467.500 MHz |
| Frequency stability: | ? ppm |
| Power supply: | 13.8 VDC |
| Current drain / power consumption: | Standby: ? mA
Talk: ? A |
| Impedance / antenna: | 50 ohm / BNC |
| Dimensions (W*H*D): | 180*52*210 mm (7.09*2.05*8.27"), without mounting frame |
| Weight: | 2.4 Kg (5.29 lb), without mounting frame |
| Other: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / impedance: | ? mW at ?% distortion / ? ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
? W
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±? KHz |
| Spurious emissions: | Better than -? dB |
| Handset impedance / connector: | ? ohm / ?-pin |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 197x-197x (Discontinued) |
| Additional info: |
This was a popular modification object for the 70 cm ham band.
|
| Related documents: | |
| Modifications and fixes: | |
| Options / Accessories: |
|
