| GENERAL |
| Type: | Airband transceiver |
| Frequency range: |
TX: 118-136 MHz
RX: 118-136 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ±?% |
| Mode: | AM |
| Channels / memory management: |
1, 6 or 10 regular (Depending on version)
Two XTALs per channel
|
| Power supply: | 12 VDC (Male 7-pin connector)
6/12 or 12/24 VDC options |
| Current drain / power consumption: | RX: 200 mA @ 12 VDC
TX: 1.5 A @ 12 VDC |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 228*70*203 mm (9*2.75*8") |
| Weight: | 2 Kg (4.5 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.5 uV (8 dB S/N) |
| Squelch sensitivity: | 0.3 uV (Threshold) |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: |
Speaker
2.5 W at 10% distortion / External speaker only
Headset
1/4" jack
|
| External speaker connector: | Female 2-pin jack (On pigtail) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
8 W
|
| Modulation system: | |
| Max AM modulation (Factory set): | ? % |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 5-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | England, 1967-1978 (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
