| GENERAL |
| Type: | 8-bit training computer |
| CPU: | Synertek 6502 @ 1 MHz |
| Operating system(s): | SuperMon
Optional Basic |
| Memory: | ROM: 4 KB (Expandable to 8 KB)
RAM: 1 KB (Max 4 KB on-board) |
| Power supply: | 5 VDC |
| Current drain / power consumption: | Max 1.5 A |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? g (? lb) |
|
|
|
|
| I/O |
| Keyboard: | Integrated 29-key keypad
Optional ASCII keyboard |
| Graphics: | Six digit LED display |
| Audio: | Piezo beeper |
| Storage: | Tape recorder (185 bytes/second) |
| External I/O ports / connectors: |
| RS-232C port: | ? |
| Tape I/O: | ? |
| Oscilloscope out: | ? (32 characters per line ) |
| Bus I/O: | ? |
|
| Other: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1978-197x (Discontinued) |
| Additional info: |
Originally called the VIM-1 (Versatile Input Monitor), but
the name was changed for legal reasons.
|
| Related documents: | |
| Modifications and fixes: | |
| Notable "ham" software: | |
| Reviews: | |
| Some options / Accessories: |
|
