| GENERAL |
| Type: | HF receiver |
| Frequency range: |
0.54-18.6 MHz in four bands
1: 0.54-1.6 MHz
2: 1.35-3.58 MHz
3: 3.4-8.9 MHz
4: 8.5-18.6 MHz
|
| Tuning steps: | Analog / continuous |
| Frequency stability: | ? ppm |
| Mode: | AM / CW |
| Channels / memory management: |
None
|
| Power supply: | Mains: 115 V AC/DC |
| Current drain / power consumption: | 78 W / 620 mA |
| Antenna impedance / connector: | Hi-Z / ? |
| Dimensions (W*H*D): | 457*320*489 mm (18*12.6*19.25") |
| Weight: | 25 Kg (55 lb) |
| Other features: | Phono input. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 500 mW at ?% distortion / 4 ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 19xx-19xx (Discontinued) |
| Additional info: |
12 tubes
|
| Related documents: |
User manual (7.8 MB)
Schematic (456 KB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
