| GENERAL |
| Type: | Amateur VHF transceiver |
| Frequency range: |
TX: 143.5-148.5 MHz
RX: 143.5-148.5 MHz
|
| Tuning steps: | 10 / 100 KHz, 1 MHz and a +5 KHz button |
| Frequency stability: | ±? ppm |
| Mode: | FM |
| Channels / memory management: |
None
|
| Repeater shift / offset: | ±600 KHz |
| Power supply: | 12.6-16 VDC |
| Current drain / power consumption: | RX: 550-750 mA
TX: Max 4 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 184*70*260 mm (7.24*2.76*10.24") |
| Weight: | ? Kg (? lb) |
| Other features: | CTCSS/PL. Dimmer. Scanning. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
Max 15 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1980-1983 (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
