| Type: | VHF/UHF receiver/scanner |
| Frequency range: | 77.5125-79.9875 / 410-412.475 MHz |
| Mode: | FM |
| Receiver system: | Dual conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz |
| Sensitivity: | 0.2 uV (12 dB SINAD) |
| Selectivity: | |
| Image rejection: | |
| Voltage: | 13.8 VDC |
| Current drain: | Max ? mA |
| Impedance: | 50-75 ohms / DIN41585 (Motorola) |
| Dimensions (W*H*D): | 140*50*190 mm (5.51*1.97*7.48") |
| Weight: | ? Kg |
| Manufactured: | Japan, 1987-198x (Discontinued) |
| Other: |
200 channels @ 100 ch/second.
Was tailor-made for the now withdrawn Swedish police and rescue bands
New price 1987 in Sweden: 1985:- SEK
|
| Related documents: | |
| Modifications: | |
