| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: |
29-54 / 108-174 / 406-512 / 800-956 MHz
|
| Tuning steps: | 5 or 12.5 KHz (Depending on band) |
| Frequency stability: | ? ppm |
| Mode: | AM / FM |
| Channels / memory management: |
100 regular in 10 banks @ 100 channels per sec
10 priority
10 skip
7 NOAA WX channels
RAM storage with supercap backup (~7 days memory retention)
|
| Power supply: | 10 VAC (From AC144U adapter) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 229*60*190 mm (9*2.38*7.5") |
| Weight: | 626 g (1.38 lb) |
| Other features: | Data skip function. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.8 MHz
2nd IF: 450 KHz
|
| Sensitivity: |
29-54 MHz: 0.3 uV (12 dB SINAD)
118-137 MHz: 0.8 uV
137-174 MHz: 0.4 uV (12 dB SINAD)
406-512 MHz: 0.5 uV (12 dB SINAD)
806-956 MHz: 0.5 uV (12 dB SINAD)
|
| Selectivity: |
20 KHz (-6 dB, 162.4 MHz)
30 KHz (-50 dB, 162.4 MHz)
|
| Image rejection: | |
| AF output power / speaker: | Max 1.2 W at 10% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1994-199x (Discontinued) |
| Additional info: | |
| Related documents: |
User manual (1.8 MB)
FM-IF: MC3361
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
AT-248
ESP-25
|
Telescoping antenna
External speaker, 8 ohm
|
|
